Inovelli Smart Plugin 2 Channels NZW37

Z-Wave Plug w/Built-in Z-Wave Repeater, On/Off Z-Wave Switch (Appliance) works with SmartThings, Wink, Vera (UL Listed, Zwave Cert) | Inovelli

../../../_images/inovelli_2channel_nzw37.jpg

Specification

  • Model: ZW37 (2-Channel)
  • Power: 120V AC, 60Hz.
  • Signal (Frequency): 908.42 MHz.
  • Maximum load for the Z-Wave controlled outlets: 10Amp Max * 2-Channel (10Amp Total, not per outlet)
  • Range: Up to 100 feet line of sight between the Wireless Controller and the closest Z-Wave receiver module.
  • Operating Temperature Range: 32-104° F (0-40° C)
  • For indoor use only.

Operation

  • Must not exceed 600 watts (Incandescent): 1200W (10A) Resistive or 1⁄2 HP
  • Motor. Total load capacity for both outlets is 1200W (10A) Resistive.
  • Two Z-Wave controlled AC outlet for standard incandescent lighting, CFL/LED, fans or small appliances
  • Remote ON/OFF control via a Z-Wave controller (2-Channels)
  • Manual ON/OFF control with the front panel push button
  • Space efficient design
  • Does not block the lower outlet when plugged into the upper outlet of a duplex wall receptacle (This assumes that the duplex receptacle is mounted with the ground pin down).
  • Plugs and cords for connected devices route to the side allowing close placement of furniture
  • Grounded 3-wire power connection for safet

Inclusion/Exclusion to/from a network

  1. Put controller to Inclusion/Exclusion mode
  2. Press in and release the toggle button 3-5 times within 3 seconds. Device will be included/excluded to/from zwave network.

Factory reset

  1. If plugged in, unplug the smart switch from the receptacle.
  2. Press and hold the top button for at least 3 seconds while you plug the switch into a recepticle
  3. Use this procedure only in the event that the network primary controller is missing or otherwise inoperable.

Configuration description

There is no configuration in this device.
